Mechanical ultra-fine grinders feature a horizontally mounted grinding disc and a vertically installed grading wheel, each driven independently. Material is evenly fed into the grinding chamber by the feeding system, where it undergoes intense impact from the high-speed rotating grinding disc. Centrifugal force further drives the material to collide with the grinding ring. The combined effects of impact, shear, friction, and collision achieve the desired particle size reduction.
Core Mechanical Issues
Incorrect Hammer Installation – If hammers are flipped or reversed during use, all must be adjusted simultaneously to avoid rotor imbalance.
Hammer Weight Discrepancy – A weight difference exceeding 5 grams between corresponding hammer sets can cause vibration. Weigh and adjust to keep deviations below 5 grams.
Stuck Hammers – If hammers fail to swing freely during operation in grinders, localized imbalance occurs. Manually rotate hammers after shutdown to ensure smooth movement.
Rotor Component Imbalance – Other rotor parts such as pins and spacers may also contribute to imbalance. Inspect and adjust each component.
Bent Spindle – Prolonged overloading or external impacts can bend the spindle. Straighten or replace as needed.
Bearing Failure – Excessive bearing clearance or damage can misalign the rotor. Replace bearings and readjust clearance.
Motor Misalignment – If the motor and grinder rotors are not concentric, adjust motor positioning or add shims under the motor base.
Uneven Support Surface – Non-level bearing seats can cause misalignment. Use copper shims or adjustable wedges to ensure concentricity.
Installation and Connection Issues
Loose or untightened anchor bolts may lead to machine shaking. Secure all bolts and install vibration dampeners between the base and equipment.
Misaligned couplings between the motor and rotor can cause localized vibration. Adjust connections based on coupling type.
Improper Connections with Other Equipment
Rigid connections such as feed and discharge pipes can transmit vibrations. Replace with flexible connections like rubber hoses to minimize vibration transfer.
Operational and Maintenance Issues
Foreign objects in the grinding chamber disrupt rotor balance. Clean the chamber before startup and regularly inspect hammer wear, replacing symmetrical hammers as needed.
Post-repair motor imbalance requires dynamic balancing tests to ensure proper alignment with the rotor.
Idling may cause rollers to collide with the grinding ring—install roller limiters to prevent this. Overloading accelerates wear; strictly control feed volume.
Special Grinder-Specific Issues
Overly Fine Material – Excessively small particles may cause empty operation. Adjust feed size or grinding pressure.
Loose Screws – Regularly inspect and tighten all fasteners to prevent abnormal vibrations.
Troubleshooting and Prevention
Immediate Shutdown – Halt operation upon abnormal vibration to prevent damage or hazards.
Systematic Inspection – Follow a rotor-motor-connection-operation sequence, prioritizing core mechanical issues.
Scheduled Maintenance – Establish a maintenance plan to inspect hammers, bearings, bolts, and other critical parts.
Standardized Operation – Control feed size and volume to avoid idling or overloading, ensuring stable performance.
